Place of Origin: | China |
---|---|
Hàng hiệu: | AI |
Chứng nhận: | ISO |
Model Number: | AIC-1743 |
Minimum Order Quantity: | 1 set ASTM D1743 Corrosion Preventive Properties Analyzer |
Giá bán: | Negotiable |
Packaging Details: | ASTM D1743 Corrosion Preventive Properties Test Analyzer packed in hardboard |
Delivery Time: | 30 days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 100 sets per month |
Test standard: | GB/T5018,ASTM D1743 | Power Supply: | AC220V±10%,50HZ |
---|---|---|---|
Motor speed: | 1450r/min | Dimension: | 360*480*550mm |
Total power: | 800W | Weight: | 18KG |
Display: | Digital | Warranty: | 1 Year |
Điểm nổi bật: | corrosion analyzer,ASTM D1743,Corrosion Preventive Properties Analyzer |
Coat the sample on a new bearing and run it for 60 seconds under a light thrust load to distribute the grease as it is used. The bearing is stored for 48 hours at 52 degrees and 100% relative humidity, and then clean and inspect for signs of corrosion on the outer ring raceway of the bearing.
Main feature
◆ The Corrosion Preventive Properties Analyzer is equipped with a set of mechanical greasers and a set of thrust loader;
◆ Automatically control the running time, and automatically shut down when the test requirements are reached;
◆ Bearing meets standard requirements;
◆ Digital display of working hours.
Technical specifications
Model | AIC-1743 |
Applicable standard | GB/T5018,ASTM D1743 |
Motor speed | 1450r/min |
Power supply | AC220V 50HZ |
Total power | 800W |
Dimension | 360*480*550mm |
Weight | 18KG |
Accessories List
No. | Name | Specification | Quantity |
1 | Corrosion Preventive Properties Test Equipment | 1 Set | |
2 | Shaft loading accessories | 1 Set | |
3 | Mechanical greaser | 1 Set | |
4 | Pliers | 1 PC | |
5 | Standard bearing | 1 PC | |
6 | Fuse | 20(A) | 4 PCS |
7 | Injector | 100ml | 1 PC |
8 | Silicon tube | Φ4 | 1 Root |
9 | Manual book | 1 Copy |
